Wheeled excavators
714MWe
714MWe, is the perfect combination of compactness and performance.
With a short radius of 1.600 mm, the 714MWe works in a single lane. The kinematics of its equipment render it effective even in extremely restricted working zones (total excavator rotation in less than 3.720 mm). Turning radius of 4.440 mm with 4 steered wheels and the possibility to advance in crab mode minimising movement on site.
| Total operating weight (kg) | 14100/15200 |
|---|---|
| Overall width (mm) | 2520 |
| Tail swing radius (mm) | 1600 |
| Turning width (mm) | 3425/2850 |
| Moc kW/KM | 88/119 |
| Max. depth (mm) | 4550 |
| Max. load weight (mm) | 8200/9000 |
| Rear penetration force (daN) | 5550/6200 |
| Rear breakout force (daN) | 8000/8400 |
| Travel speed (km/h) | 33 |
| + and - with forks (ml) | + 7400/- 3260 |
- Mechanical rapid coupling with hydraulic unlatching (Mecalac patent)
fast coupling of the correct tool in total safety - Coupling of cylinders (Mecalac patent)
Easy to use and exploit the full scope of equipment operation - Main boom lifting with 2 asymetric actuators (MECALAC patent)
for constant lifting torque over the entire working radius - Sliding-swing door (Mecalac patent)
Easy and safe access to the driver's cab even in narrow space - Retractable steps (option)
Easy and safe when entering or leaving the driver's cab - Buscan electronic control system
for optimum power control - Load sensing 'flow sharing'
provides a proportional supply in accordance with the load required
