Revotruck-Series
Revolution in
a 9-Ton Payload
Edition
The Revotruck 9 is the expression of this game-changing revolutionary design in a 9-ton payload version.
Mecalac has created the Revotruck, a unique piece of engineering that combines the revolution of the cab with off-road truck capabilities. Operators can now rotate the entire cab at the touch of a button to keep their vision and focus on the job and obstacles on site. The exclusive chassis with central oscillation ensures stability and traction in all ground conditions.
Together with extreme ease of use and accessibility, the Revotruck makes material transport smarter and safer.
While maintaining the innovative Mecalac features and leveraging the extensive expertise from the site dumper manufacturing and market, the Revotruck 9 not only provides an increased payload capacity of up to 9 tons (19,841 lbs) but also embodies the concentrated excellence observed in the 6-T version.
Specifications
| Total operating weight | 6565 kg (14,473 lbs) | |
|---|---|---|
| Engine power | 55 kW (74 hp) | |
| Skip type | Swivel | |
| Payload | 9000 kg (19,842 lbs) | |
| Maximum skip capacity (Heaped) | 4,5 m3 (5.9 yd3) | |
| Transmission | Hydrostatic | |
| Travel speed | 28kph (17.4mph) | |
| Operator environment | ROPS / FOPS Rotating Cab 225° | |
| Overall width | 2412 mm (7’11’’) | |
| Overall length | 5270 mm (17’3’’) | |
| Overall height | 2856 mm (9’4’’) | |
| Dumping height, skip tipped | 1117 mm (3'8'') |
