Gleisbau 106MRail

106MRail

Performing compactness

The 106MRail is the smallest end of our MRail product line. In this size and with such a ease of use, it’s the perfect utility machine to support larger equipment.

106MRail in Aktion

Videos

Merkmale

Gewicht9 475 kg (20,889 lbs)
Boom typeMecalac boom with offset
Fahrgeschwindigkeit10 kph (6.2 mph)
Geschwindigkeit (Schienen)23 km/h (14.3 mph)
Motorleistung (kW/PS)75 ch (55.4 kW) à 2300 tr/min (rpm)
Emissions standardsEU Stage V / U.S. EPA Tier 4 Final
Maximum torque300 Nm (221 lbf) à 1600 tr/min (rpm)
GetriebeCrawler closed circuit
Getriebe (Schienen)Hydrostatic
Possible Track Widths950-1600 mm (3’1.4’’-5’3’’)
Hubkraft in max. HöheAt 3 m (10 ft) and 0°. Height: 3 m (10 ft): 2T
At 6 m (19’8’’) and 90°. Height: 3 m (10 ft): 550 kg (1,212 lbs)
Traction capacity at the tow bar1 400 kg (3,086 lbs)
Traction capacity - maximum Trailer8 t (17,637 lbs)
Pneumatic Braking SystemNEIN
Height and Swing LimitersJA
RCI Load LimiterNEIN
